Amps to Megawatts Conversion
Amps to Megawatts (MW) conversion depends on the voltage and power factor of the system. The formula varies based on whether it’s a DC, single-phase AC, or three-phase AC system
Ampere (A)
A unit of electric current measuring the rate of electric charge flow. One ampere equals one coulomb per second.
Megawatt (MW)
A unit of power measuring the rate of energy usage. One megawatt equals one million watts.
DC Circuit Calculation
Where:
- P = Power in Megawatts
- I = Current in Amps
- V = Voltage in Volts
AC Single Phase Calculation
Where:
- PF = Power Factor
- I = Current in Amps
- V = RMS Voltage in Volts
AC Three Phase Calculation
Line to Line:
P(MW) = (โ3 ร PF ร I(A) ร VL-L(V)) / 1,000,000Line to Neutral:
P(MW) = (3 ร PF ร I(A) ร VL-N(V)) / 1,000,000Typical Power Factor Values
| Device | Typical Power Factor |
|---|---|
| Resistive Load | 1.0 |
| Fluorescent Lamp | 0.95 |
| Incandescent Lamp | 1.0 |
| Induction Motor (Full Load) | 0.85 |
| Induction Motor (No Load) | 0.35 |
| Synchronous Motor | 0.90 |
Important: These are typical values. For accurate calculations, use the actual power factor of your device.
Quick Reference Table (120V)
| Current (A) | Voltage (V) | Power (MW) |
|---|---|---|
| 0.1 | 120 | 0.000012 |
| 0.2 | 120 | 0.000024 |
| 0.3 | 120 | 0.000036 |
| 0.4 | 120 | 0.000048 |
| 0.5 | 120 | 0.000060 |
| 0.6 | 120 | 0.000072 |
| 0.7 | 120 | 0.000084 |
| 0.8 | 120 | 0.000096 |
| 0.9 | 120 | 0.000108 |
| 1.0 | 120 | 0.000120 |
| 2.0 | 120 | 0.000240 |
| 3.0 | 120 | 0.000360 |
| 4.0 | 120 | 0.000480 |
| 5.0 | 120 | 0.000600 |
| 6.0 | 120 | 0.000720 |
| 7.0 | 120 | 0.000840 |
| 8.0 | 120 | 0.000960 |
| 9.0 | 120 | 0.001080 |
| 10.0 | 120 | 0.001200 |
FAQs
What is the difference between Amps and Megawatts?
Amps measure the flow of electric current, while Megawatts measure the rate of energy usage on a much larger scale. The relationship between them is defined by the voltage in the circuit.
How do I convert Amps to Megawatts?
To convert Amps to Megawatts, use the formula: P(MW) = (I(A) ร V(V)) / 1,000,000. You need to know the voltage to perform this calculation.
What is a Power Factor?
The Power Factor (PF) is a measure of how effectively electrical power is being converted into useful work output. It is the ratio of real power (Watts) to apparent power (Volt-Amps).
Why is the Power Factor important?
A low power factor indicates poor efficiency, which can lead to higher energy costs and potential penalties from utility companies.
Reference
- Power Formulas in DC and AC Single-Phase & Three-Phase Circuits
